Sharp GCT1118H

machine specifications

• Swing Over Carriage:

  9"

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• DISTANCE BETWEEN CENTERS:

  18"

• Swing over cross slide:

  6"

• Swing over Bed:

  20.1?

• Throat Depth:

  9.45"

• Spindle With Round 5C Collets:

  11/16"

• Spindle With Hexagon 5C Collets:

  7/8"

• Spindle With Square 5C Collets:

  3/4"

• Spindle With Expanding Chucks:

  3"

• Spindle With Step Chucks:

  1 1/16-6"

• Spindle With Jaw Chucks:

  5"

• Spindle Speed Range (infinitely variable DVS):

  130-4,000 rpm

• Spindle Nose Taper:

  (inside): 5C (10º)

• Spindle Nose Taper (outside):

  4º

• Cross slide travel:

  6"

• Compound slide travel:

  3"

• Quick-action compound slide travel:

  0.1"

• Carriage power feed range:

  5/16-7"

• Cross slide power feed range:

  4/16-4"
