Pines CNC-100 2017

Sold Image

THIS MACHINE HAS SOLD AND IS NO LONGER AVAILABLE. WE MIGHT STILL HAVE A SIMILIAR MODEL OR EXACT MATCH. BROWSE CURRENT INVENTORY OR CONTACT AN AGENT BELOW.

Loading highlight...

  • MAKE: Pines

  • MODEL: CNC-100

  • YEAR: 2017

  • TYPE: Tube Benders

  • CONTROL: TS CNC

  • REF #:

MACHINE SPECIFICATIONS

  • Steel Tubing Y.P. to 40,000 PSI:

    4" x .109"

  • Motor:

    40 HP 30Kw

  • Operating Pressure:

    2000 PSI

  • Stainless Steel Y.P. to 60,000 PSI:

    4" x .065"

  • Reservoir Capacity:

    100 Gallons

  • Non-Ferrous Tubing Y.P. to 25,000 PSI:

    4" x .188"

  • Weight:

    4500 lbs

  • Steel Pipe Schedule 80:

    2.5"

  • Standard Bend Radius to Centerline:

    12"

  • Standard Max. Tube Length Over Mandrel:

    136"

  • Standard Carriage Travel:

    72"

  • Carriage Travel (Y Motion):

    +- .005"

  • Collet Rotation (B Motion):

    +- .10 Degrees

  • Bend Arm Rotation (C Motion):

    +- .10 Degrees

  • Bend Arm Rotation:

    195 Degrees

  • Collet Rotation:

    360 Degrees

  • Overall Length:

    226"

  • Length of Arm:

    38"

  • Bed Length:

    188"

  • Centerline Height:

    3"

  • Undernose Clearance:

    30"

  • Working Height:

    42"

  • Maximum Bend Angle (+allowance for spring back):

    180 Degrees

  • Max Bend Arm Rotation:

    195 Degrees

  • Over-Mandrel Tube Length:

    136"

  • Bending Arm Speed:

    21 RPM

MACHINE EQUIPPED WITH

  • $38000 WORTH OF TOOLING
  • 120 INCH BASE EXTENSION
  • SWING AWAY WIPER DIE HOLDER
  • HITCH FEED
  • SPRINGBACK COMPENSATION
  • DUAL SPINDLE SWING ARM
  • PDI ZONE RECAPTURE
  • WIPER DIE HOLDER
  • LASER SAFETY SCANNER
  • QUICK DISCONNECT MANDREL ROD
  • REMOTE OPERATOR CONTROL STAND
  • COUNTER CLOCKWISE ROTATION
  • MANDREL EXTRACTOR WITH MANDREL ROD
  • HEAVY DUTY AUTOMATIC MANDREL LUBRICATOR
  • TWIN OVERHEAD TIE BARS
  • FAN COOLED HEAT EXCHANGER
  • HYDRAULIC INLINE PRESSURE DIE ASSIST
  • INDEPENDENT CLAMP & PRESSURE DIE OPERATION (Independent Tools)
  • AUTOMATIC SLIDE LUBRICATOR
  • FAN COOLED HEAT EXCHANGER
