Amada EMK 3610NT 2011

MACHINE SPECIFICATIONS

• Capacity:

  33 tons

• Sheet Width:

  60"

• Sheet Length:

  100"

• Turret Stations:

  58

• Throat Depth:

  4 A/I (2 X 11/4" And 2 X 41/2")

• Feed clearance:

  .984"

• Axis Speed:

  X-Axis: 3950"/Min. Y-Axis: 3150"/Min.

• HPM:

  500 HPM (0.197" Stroke & 1"Pitch) 780 SPM (0.197" Stroke & 0.039" Pitch) 1800 SPM (0.055" Pitch Marking)

• Material Thickness:

  0.24 Gauge – 1/4"

• Loading height:

  Maximum Is 10.25" Including Skid Height Of 4"

• Slide Type Die Holder :

  Standard

• Maximum Material Weight:

  5,500 Lbs

• Material:

  Mild Steel, Stainless Steel, Aluminum

• Number of Pallets:

  2 Pallets (Raw Materials and Finished Parts)

• Electrical Requirements:

  230v/460v – 3 Phase

• Electrical Supply:

  10 Kva (Not Including NCT Machine)

• Air Requirements:

  75 PSI, 31.8 CFM

• Material Separation:

  Edge Lifter, Magnetic Separator, Air Knife

• Overall Dimensions:

  201" X 163" X 105"
