Amada Vipros 255 1999

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Resonator ( Type ):

  55

• Table Size - W:

  30"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Press Capacity:

  22 U.S. tons

• Max. Sheet Size:

  50" x 100"

• Max. Sheet Thickness:

  0.25"

• Max. Sheet Weight:

  231 lb. at axial feed-speed F4

• Max. Sheet Weight:

  136 lb. at axial feed-speed F1

• Punching Accuracy:

  .003" or .002" in high accuracy mode operation

• Strokes per minute (X)::

  .31" pitch - 10 strokes

• Strokes per minute (X):

  1" - 280 strokes

• Strokes per minute (Y):

  .31" pitch - 380 strokes

• Strokes per minute (Y):

  1" pitch - 280 strokes

• Max. Ram Stoke Length:

  1.57"

• Max. Feed Speed (X):

  312 ft/min.

• Max. Feed Speed (Y):

  164 ft/min.

• Turret Speed:

  35 RPM

• Power Supply:

  22 kVA

• Air Supply:

  250 liters/min.

• Operating Air Pressure:

  72 PSI
