Trumpf Trumatic TC600L 2001

machine specifications

• Max Swing (inches):

  17.32"

• Chuck Size (Inches):

  8"

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Pallet Size (inches):

  25"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Speed (X Axis):

  3543.31 IPM

• Speed (Y Axis):

  2362.3 IPM

• Speed (X And Y):

  4251.97 IPM

• C Axis (Tapping):

  1 Rotation/S (3 Rot./S)

• Max. Sheet Thickness:

  0.315"

• Max. Punching Tonnage:

  22 Tons

• Max. Workpiece Weight:

  440 lbs.

• Max. Forming Height:

  .46"

• Max. Number Of Tools:

  19

• Max. Part Size:

  19.6'’ X 19.69"

• Laser Power:

  2400 Watts

• Laser Mode (X,Y):

  121" x 53.93"

• Stroke Rate (Punching):

  600 Hits/Min

• Stroke Rate (Engraving):

  1700 Hits/Min

• Single Stroke (Max. Punch Dia.):

  2.99"

• Punching Mode (X,Y):

  121" x 50.39"

• Standard Mulitcut (Max. Punch Dia):

  7.87"

• Rotation Of All Tools:

  360 Degrees

• Linear Tool Mag.:

  19 Tool Stations

• Combined (X,Y):

  101.77" X 50.39"

• Tool Change Time:

  1.5 – 5s

• Positioning Accuracy:

  ±0.0004"

• Repeatability:

  ±0.0012"

• Monitor:

  9.5" Color
