Mori Seiki NZX 2500 2015

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Pallet Size (inches):

  25"

• Swing over Bed:

  30.7”

• Max. turning diameter (Turret 1):

  14.5"

• Max. turning diameter (Turret 2):

  10.2"

• Max. Turning Length:

  23.6

• X-Axis Travel (Turret 1):

  8.9”

• X-Axis Travel (Turret 2):

  6.7”

• Z-axis travel (Turret 1):

  25.6”

• Z-axis travel (Turret 2):

  25.6”

• THROUGH-SPINDLE HOLE DIAMETER:

  2.9"

• Spindle Speed Standard:

  4,000 RPM

• Number of Spindle Speed Ranges:

  1

• Spindle Nose:

  A2-8

• Spindle bearing inner diameter Standard:

  5.5”

• Chuck:

  10" hollow

• Number of tool slides:

  2

• Number of Tool Slides (Turret 1 ):

  12

• Number of Tool Slides (Turret 2):

  8

• Shank Height For Square Tool:

  1

• Shank diameter for boring bar:

  2.0”

• Turret indexing time sec:

  0.2

• Rapid traverse rate: X1-axis:

  984.3 IPM

• Rapid traverse rate X2-axis:

  984.3 IPM

• Rapid traverse rate Z1-axis:

  1,181.1 IPM

• Rapid traverse rate Z2-axis:

  1,181.1 IPM

• Jog Feedrate:

  196.9 IPM <20 steps>

• Tailstock Travel:

  23.6”

• Tailstock Spindle Diameter:

  4.3”

• Tailstock Spindle Travel:

  5.9"

• Standard <10 min/30 min/cont>:

  34.7/34.7/30 HP

• Coolant Tank Capacity:

  105.6 gal.

• Taper:

  MT4
