KDM KTM 16/20 2009

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Table Size - L:

  61"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Resonator ( Type ):

  55

• X Axis Saddle Horizontal Travel:

  -9.8" - 58.3"

• Z Axis Ram Vertical Travel:

  35.4"

• C Axis Drive Motor:

  AC Servo 4.0

• Max Swing (inches):

  17.32"

• Maximum Turning Height:

  40.2"

• Distance from Table to Milling Spindle End:

  36.4"

• Maximum Table Speed:

  1- 350 rpm

• Table Indexing:

  0.001 Degree

• Maximum Load of Workpiece:

  13,200 lb

• Milling Spindle Speed:

  1 - 2,000 rpm

• Crossrail Up Down Travel:

  FIXED

• Table Motor:

  AC37/45 kw

• Live Spindle Motor:

  AC 15 / 18.5 kw
