You-Ji VTL 1600 ATC + C 2011

machine specifications

• Spindle Motor (HP):

  37/45

• X - Axis Travel (inches):

  15.7" / 400mm

• Max Swing (inches):

  17.32"

• Tool Changer Type:

  60 ATC

• Spindle Speed:

  12,000 RPM

• Table Diameter:

  63"

• Maximum Cutting Diameter:

  70.86"

• Maximum Cutting Height:

  47.24"

• Maximum Load Table:

  17640 lbs.

• Horizontal Travel of Rail Head:

  48.22"

• Vertical travel of Crossrail:

  27.55"

• Table Speed Low/High:

  2-62 / 64-250

• Maximum Table Torque:

  19,600

• Rapid Traverse of Rail Head (X-Axis):

  39.37/min.

• Rapid traverse of ram (Z-axis):

  32.80"/min.

• Cutting Feed Rate:

  .039"- 7.85" /min.

• Manual feeder rate:

  0 - 32"/min.

• Turret Capacity:

  8 Positions

• Type of Tool Shank:

  7/24 Taper BT-50

• Maximum No. of Tool Size for Automatic tool Changing:

  280Wx150Tx400L

• Maximum Tool Weight:

  50kg

• Maximum Loading of ATC:

  60 kg

• Tool Change Time:

  40 sec.

• CF-Axis Servo Motor:

  7 (a30i)

• Coolant motor:

  0.18kw

• Power capacity:

  100

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Bar Stock Capacity:

  2.0"

• Y - Axis Travel (inches):

  15.7" / 400mm

• Throat Depth:

  9.45"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Chuck Size (Inches):

  8"
