Cincinnati U5 1999

machine specifications

• Vertical Travel of Ram:

  4444

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Chuck Size (Inches):

  8"

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Pallet Size (inches):

  25"

• Options:

  Cutting Heads 1- Contour head 5 axis 6,000 RPM 2- Hi Speed 5 axis head 24,000 Rpm 3- 3 axis head 6,000 RPM. 40 motor Table specs 171"L x 66" W

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Max Swing (inches):

  17.32"
