Doosan DNM400 2010

machine specifications

• Chuck Size (Inches):

  8"

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Table Size - W:

  30"

• Table Size - L:

  61"

• Table Capacity:

  1320 lbs.

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Motor (HP):

  20 HP

• Spindle to Table Distance:

  30"

• Spindle Center to Column Distance:

  20.2"

• Tool Changer Type:

  60 ATC

• Tool Changer Style:

  Twin Arm Automatic Tool Changer

• Tool Change Time:

  1.3 sec.

• Max Tool Length:

  11.8"

• Max Tool Weight:

  17.6 lbs.

• Maximum Cutting Feed Rate:

  590 ipm

• Rapid Traverse Rate (X/Y/Z):

  1417 / 1417 / 1181

• Hours:

  144 - Power On
