Fadal 4020 1996

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Chuck Size (Inches):

  8"

• Throat Depth:

  9.45"

• Resonator ( Type ):

  55

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Table Size - L:

  61"

• Table Size - W:

  30"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Center to Column:

  20"

• Maximum Tool Diameter:

  3"

• Maximum Tool Length:

  15"

• Maximum Tool Weight:

  15 lbs.

• Tool Changer Type:

  60 ATC

• Rapid Feed Rate:

  400 IPM X, Y, Z.

• Cutting Feed Rate:

  .01" to 150" X, Y, Z.

• Floor Line to Table Top:

  31"
