Fadal 4020 HT 2007

machine specifications

• X Axis Travel:

  40"

• Y Axis Travel:

  20"

• Z Axis Travel:

  20"

• Rapid Traverse Rate:

  900 inch per minute

• Spindle Nose to Table (Min.- Max.):

  4" - 24"

• Table Length:

  48"

• Table width:

  20"

• Number of STD T-Slots:

  5

• Max Weight on Table:

  3500 lbs

• T-Slot Width:

  5/8"

• Spindle Taper Size:

  CAT 40

• SPINDLE SPEED RANGE:

  0 - 10,000 RPM

• spindle power:

  20 HP

• Max Torque:

  230 ft-lb 500 RPM

• ATC Capacity:

  20 + 1

• Max Tool Weight:

  15 lbs

• Max Tool Dia:

  6"

• Max Tool Length:

  15"

• Tool changing time:

  4.2 seconds

• Power:

  240V / 30 KVA / 3-Phase

• Overall Dimensions:

  122" x 100" x 100" High

• Air Required:

  100 psi, 4 scfm

• Weight:

  12,500 lbs
