Haas Mini Mill 2015

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Resonator ( Type ):

  55

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  7.5

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle nose to table (~ max):

  14"

• Spindle nose to table (~ min):

  4"

• Max Torque:

  33 ft-lb @ 1200 rpm

• Drive System:

  Direct Speed Belt Drive

• Bearing Lubrication:

  Grease Packed

• Cooling:

  Air Cooled

• Table Size - W:

  30"

• Table Size - L:

  61"

• Length (Work Area):

  28.75

• T-Slot Width:

  5/8 "

• T-Slot Center Distance:

  4.33 "

• Number of STD T-Slots:

  3

• Max Weight on Table (evenly distributed):

  500 lbs.

• Rapids on X/Y/Z:

  600"/min.

• Max Thrust X/Y/Z:

  2000 lb

• Type:

  Carousel

• Tool Changed Capacity:

  10

• Max Tool Diameter (full):

  3.5 "

• Max Tool Weight:

  12 lb

• Air Required:

  4 scfm, 100 psi

• Coolant Capacity:

  40 gal
