Haas VF-3YT/50 2010

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Throat Depth:

  9.45"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Resonator ( Type ):

  55

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Chuck Size (Inches):

  8"

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  30 HP - 2 Speed Geared

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Nose to Table:

  4" - 29"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Max. Table Load:

  4,000 LBS

• Tool Changer Type:

  60 ATC

• Chip to Chip Tool Change Time:

  6.3 S

• Max Tool Diameter:

  7"

• Max Tool Length:

  16"

• Max Tool Weight:

  30 Lbs

• Rapid Traverse Rate:

  710 IPM

• Cutting Feedrate:

  500 IPM

• Machine Weight:

  15,900 Lbs
