Haas VF-4 SS 2011

machine specifications

• Max Swing (inches):

  17.32"

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Tool Changer Type:

  60 ATC

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Throat Depth:

  9.45"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  30 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle nose to table (~ max):

  29 "

• Spindle nose to table (~ min):

  4 "

• Length:

  52 "

• Width:

  18 "

• T-Slot Width:

  5/8 "

• Number of STD T-Slots:

  5

• Max Weight on Table (evenly distributed):

  1750 lb

• Max Rating:

  30 hp

• Max Speed:

  12000 rpm

• Max Torque:

  90 ft-lb @ 2000 rpm

• Drive System:

  Inline Direct-Drive

• Bearing Lubrication:

  Air/Oil Injection

• Cooling:

  Liquid Cooled

• Rapids on X:

  1400 in/min

• Rapids on Y:

  1400 in/min

• Rapids on Z:

  1400 in/min

• Max Cutting:

  833 in/min

• Max Thrust X:

  3085 lb

• Max thrust Y:

  3085 lb

• Max Thrust Z:

  3925 lb

• Max Tool Diameter (adjacent empty):

  5 "

• Max Tool Diameter (full):

  2.5 "

• Max Tool Length (from gage line):

  11 "

• Max Tool Weight:

  12 lb

• Air Required:

  4 scfm, 100 psi

• Coolant Capacity:

  55 gal
