Haas VF-6SS 2015

machine specifications

• Pallet Size (inches):

  25"

• Spindle Speed:

  12,000 RPM

• Chuck Size (Inches):

  8"

• Spindle Taper (CAT/BT):

  HSK-463

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Tool Changer Type:

  60 ATC

• V-Axis Travel:

  5555

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• Turret Capacity:

  8 Positions

• Spindle Nose to Table Max:

  34"

• Spindle Nose to Table Min:

  4.0"

• Max Rating:

  30.0 HP

• Max Speed:

  15000 RPM

• Max Torque:

  90 ft-lbf @ 2000 rpm

• Drive System Inline Direct:

  Drive

• Taper:

  CT 40

• Bearing Lubrication:

  Air / Oil Injection

• Cooling:

  Liquid Cooled

• Length:

  64.0"

• Width:

  28.0"

• T-Slot Width:

  0.630 in

• T-Slot Center Distance:

  4.92"

• Number of STD T-Slots:

  5

• Max Weight on Table (evenly distributed):

  2000 lb

• Max Cutting:

  833 ipm

• Rapids on X/Y/Z:

  1200 IPM/ 1200 IPM/ 1200 IPM

• Max Thrust X/Y/Z:

  3400 IBF/3400IBF/3400IBF

• Type:

  SMTC

• Capacity:

  24+1

• Max Tool Diameter (full):

  2.5"

• Max Tool Diameter (adjacent empty):

  5"

• Max Tool Length (from gage line):

  16"

• Max Tool Weight:

  12 lb

• Tool-to-Tool (avg):

  2.3 Sec

• Chip-to-Chip (avg):

  3.2 s

• Coolant Capacity:

  95 Gal

• Air Required:

  4 scfm @ 100 psi

• Inline Air Hose:

  3/8"

• Coupler (Air):

  3/8"

• Air Pressure Min:

  80 PSI

• spindle power:

  30.0 HP

• Input AC Voltage (3 Phase) - Low:

  220 VAC

• Full Load Amps (3 Phase) Low:

  70 A

• Input AC Voltage (3 Phase) - High:

  440 VAC

• Full Load Amps (3 Phase) - High:

  35 A
