Haas VF-9 /40 2015

machine specifications

• Table Size - W:

  30"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Spindle Taper (CAT/BT):

  HSK-463

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• T-Slot Center Distance:

  4.92 in

• Number of STD T-Slots:

  7

• Max Cutting:

  500 ipm

• Rapids on X, Y, & Z:

  600 IPM/ 600 IPM/ 600 IPM

• Max Thrust X,Y, & Z:

  3,400 IBF / 3,400 IBF/ 5,600 IBF

• Type:

  SMTC

• Capacity:

  40+1

• T-Slot Width:

  0.630 in

• Width:

  36"

• Length:

  84"

• Cooling:

  Liquid Cooled

• Drive System:

  Inline Direct-Drive

• Max Torque w/opt Gearbox:

  250 ft-lbf @ 450 rpm

• Max Torque:

  90 ft-lbf @ 2000 rpm

• Max Speed:

  8100 rpm

• Max Rating:

  30.0 HP

• Spindle Nose to Table (Min.- Max.):

  4"-34"

• Max Tool Diameter:

  2.9"

• Max Tool Diameter (adjacent empty):

  6"

• Max Tool Length (from gage line):

  16"

• Max Tool Weight:

  12 lb

• Tool-to-Tool (avg):

  2.8 s

• Chip-to-Chip (avg):

  3.6 s

• Coolant Capacity:

  95 gal

• Air Required:

  4 scfm @ 100 psi

• Inline Air Hose:

  3/8 "

• Coupler (Air):

  3/8"

• Air Pressure Min:

  80 psi

• Drive System Inline Direct:

  Drive

• spindle power:

  30.0 HP

• Input AC Voltage (3 Phase):

  Low 220 VAC

• Full Load Amps (3 Phase):

  Low 70 A

• Input AC Voltage (3 Phase):

  High 440 VAC

• Full Load Amps (3 Phase):

  High 35 A
