Haas VF2 1998

machine specifications

• Pallet Size (inches):

  25"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Throat Depth:

  9.45"

• Z - Axis Travel (inches):

  14.7" / 375mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• X - Axis Travel (inches):

  15.7" / 400mm

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Chuck Size (Inches):

  8"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Max Workpiece Weight:

  3,000 LBS

• Spindle Nose to Table Top:

  4" - 24"

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Motor (HP):

  20 HP

• Tool Changer Type:

  60 ATC

• Max Tool Diameter:

  3.5"

• Max Tool Length:

  9"

• Max Tool Weight:

  12 LBS

• Tool Change Time:

  4.2 Seconds

• Chip To Chip Time:

  4.5 Seconds

• Rapid Traverse Rate:

  710 IPM

• Cutting Feed Rate:

  500 IPM

• Power On Hours:

  8,500
