Haas VF-4SS 2005

machine specifications

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  30 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Nose to Table:

  29"

• Spindle Maximum Rating:

  30 HP

• Table Size - L:

  61"

• Table Size - W:

  30"

• Maximum Weight on Table (Evenly Distributed):

  170 lbs.

• T-Slot Width:

  5/8"

• T-Slot Center Distance:

  3.15"

• Number of STD T-Slots:

  5

• Maximum Tool Diameter:

  5"

• Maximum Tool Weight:

  12 lbs.

• Maximum Cutting:

  833 in/min

• Max Cutting Speed (IPM):

  833 IPM

• Maximum Tool Length (From Gage Line):

  11"

• Tool Changer Positions:

  24 Plus 1

• Tool-To-Tool (Average):

  1.6 seconds

• Chip-To-Chip (Average):

  2.2 seconds

• Feedrates (X/Y/Z):

  1,400 in/min.

• Resonator ( Type ):

  55

• Bar Stock Capacity:

  2.0"

• Tool Changer Type:

  60 ATC

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Pallet Size (inches):

  25"

• Max Swing (inches):

  17.32"

• Throat Depth:

  9.45"

• Chuck Size (Inches):

  8"
