Haas VR-11/40 2013

machine specifications

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Throat Depth:

  9.45"

• Wire Diameter (inches):

  3333

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  30 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Table Size - L:

  61"

• Table Size - W:

  30"

• Tool Changer Type:

  60 ATC

• Max Cutting:

  360 IN/MIN

• Rapids on a:

  1900 °/MIN

• Rapids on b:

  1900 °/MIN

• Rapids on X:

  360 IN/MIN

• Rapids on Y:

  600 IN/MIN

• Rapids on Z:

  600 IN/MIN

• Air Required:

  9 SCFM, 100 PSI

• B axis (rotation):

  ± 32 °

• Drive System:

  Vector Drive

• Max rating X:

  7.5 HP

• Max rating Y:

  5.0 HP

• Max rating Z:

  5.0 HP

• Max Thrust X:

  3400 LB

• Max thrust Y:

  3400 LB

• Max Thrust Z:

  3400 LB

• T-Slot Width:

  5/8 "

• A axis (tilt):

  ± 32 °

• Max cutting A:

  600 °/MIN

• Max cutting B:

  600 °/MIN

• Max Tool Weight:

  12 LB

• Coolant Capacity:

  95 GAL

• Max Tool Diameter:

  3.5 "

• Tool-to-Tool (avg):

  11.0 SEC

• Bearing Lubrication:

  Air/Oil Injection

• Repeatability a,b axes:

  10 ARC-SEC

• T-Slot Center Distance:

  4.92 "

• Positioning a,b axes (±):

  45 ARC-SEC

• Spindle nose to table (~ max):

  34 "

• Spindle nose to table (~ min):

  4"

• Max Weight on Table (evenly distributed):

  4000 LB
