Hurco VM10i 2013

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Chuck Size (Inches):

  8"

• Throat Depth:

  9.45"

• Resonator ( Type ):

  55

• Max Swing (inches):

  17.32"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Speed:

  12,000 RPM

• Spindle Motor (HP):

  15 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Torque:

  74 Nm @ 1,450 RPM (1 Min.)

• Spindle Nose to Table:

  4.02” – 24.02”

• Table Size - L:

  61"

• Table Size - W:

  30"

• Maximum Load:

  749.6 lbs.

• Table T-Slots:

  .12” x .71” x 3.9

• Tool Changer Type:

  60 ATC

• Rapid Traverse X/Y/Z:

  78.84’/min.

• Cutting Feed Rates X/Y/X:

  49.87’/min.

• Positioning Accuracy:

  .010 mm.

• Repeatability:

  .005 mm.

• Maximum Tool Length:

  9.84”

• Maximum Tool Weight:

  15.4 pounds

• Tool Change Time:

  3 seconds
