Kitamura 3XiF 2003

machine specifications

• Chuck Size (Inches):

  8"

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Table Size - L:

  61"

• Table Size - W:

  30"

• Spindle Motor (HP):

  15 HP

• Spindle Speed:

  12,000 RPM

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Nose to Table Top:

  5.7" - 23.8"

• Spindle Torque:

  110.9 ft./lbs.

• Rapid Traverse Rates X, Y / Z:

  1181 IPM/945 IPM

• Tool Magazine Capacity:

  30 Position ATC

• Tool Change Time Chip to Chip:

  3.2 Seconds

• Max. Tool Diam./Length/Weight:

  4.9"/11.8"/17.6 lbs.

• Machine Dimensions:

  106"x98"x119"

• Machine Weight:

  13,860 lbs.
