Toyoda AA1565 2008

machine specifications

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Table Size - W:

  30"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Bar Stock Capacity:

  2.0"

• Max Swing (inches):

  17.32"

• Chuck Size (Inches):

  8"

• Spindle Speed:

  12,000 RPM

• Resonator ( Type ):

  55

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Motor (HP):

  10/15 HP

• Spindle Taper (CAT/BT):

  HSK-463

• Dis. Spindle to Nose Table:

  4.9”-28.5”

• Table Size (X Direction):

  65.0”

• Table Size (X Direction):

  25.6”

• Table Load Capacity:

  3,300”

• Spindle Speed Gear Driven:

  6,000 RPM

• Rapid Traverse (X Axis):

  590.6

• Rapid Traverse (Y Axis):

  590.6

• Rapid Traverse (Z Axis):

  472.4

• Cutting Federate:

  0.04-315

• Tool Magazine Capacity:

  20 Pcs

• Max. Tool Diameter:

  4.3”

• Max. Adj. Pocket Empty:

  7.9”

• Max. Tool Length:

  11.8”

• Max. tool weight:

  33 Lbs

• Pos. Accuracy (VDI/DGQ 3441):

  0.0006”

• Repeatability (VDI/DGQ 3441):

  0.0003”
