Honor Seiki VL-125CM 2012

machine specifications

• Max Swing Diameter:

  63"

• Max Turning Diameter:

  63"

• Distance from Ram to Table:

  25.6" - 57"

• Max Turning Height:

  49.21"

• Max Workpiece Weight:

  11,023 lbs.

• ATC:

  16- position

• Horizontal Travel (X-Axis):

  37.4"

• Range of table speed:

  3-300 rpm

• Change gear speed:

  2-step

• Vertical Travel (Z Axis):

  35.4"

• Feed Override:

  0-150%

• Spindle Motor:

  50 HP/ 60 HP (Cont./ 30Min)

• Spindle Taper:

  BT50

• Floor Space:

  230" x 149" (L x W)

• Standard Net Weight:

  53,900 lbs

• Chuck Size:

  50"

• Spindle Speed:

  300 RPM

• Rapid Traverse Rate:

  393 IPM

• Live Tool Motor:

  20 HP

• Live Tool Speed:

  50 - 2250 RPM

• Cross Rail Travel:

  31.49" (7.87" x 4 Steps)

• Ram size:

  8.66" sq.

• Spindle Torque:

  9878 ft. lbs.
