Mitsubishi Suprema 510 2011

machine specifications

• Tool Changer Type:

  60 ATC

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Table Size - W:

  30"

• Throat Depth:

  9.45"

• Turret Capacity:

  8 Positions

• V-Axis Travel:

  5555

• Vertical Travel of Ram:

  4444

• Wire Diameter (inches):

  3333

• Wire Traveling Speed:

  22

• Resonator ( Type ):

  55

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Max workpiece dim.:

  88” x 165.7” x 6.0”

• Submerged Machining Depth:

  3.0”

• Working Table Height From Floor:

  36”

• Rapid Travel Speed:

  787 IPM

• Tank Weight:

  Approx 5,950 lbs

• Tank Volume:

  1,664 Gal.

• Intensifier Pump:

  KMT SL PRO 125

• No. of Intensifiers:

  2

• Max Operating Pressure:

  90,000 PSI

• Motor Power:

  125 HP

• Water Consumption:

  Approx 2.0 GPM

• Max. Orifice Size:

  0.013”

• Machine/Pump Voltage:

  230V/460V

• Control Unit:

  Mitsubishi M700

• Program Support Function:

  Metamation METCAM

• Program Input Capabilities:

  Ethernet, USB, PCMCIA

• Graphic Display:

  15” Waterproof TFT LCD

• CPU/Type:

  M700/Industrial PC

• Abrasive Hopper Capacity:

  670 LBS
