159" Light curtain opening, 118" Headstock-tailstock span, 95" Main Axis rotation diameter, 60.4" Robot CL to Positioner Faceplate
Make: Panasonic
Model: PerformArc 3000
Year: 2010
Control: - Panasonic
Type: Welding Cell
Reference: 3675353
-
Max Payload 17.637lbs
-
Cell Width 221"
-
Cell Depth 180"
-
Cell Height 90"
-
Cell Main Base Depth (excluding wings) 136"
-
Wing Inset (right hand side) 20.5"
-
Wing Inset (left hand side) 31.5"
-
Outboard Positioner CL (from floor) 40.3"
-
Inboard Positioner CL (from floor) 62.1"
-
Inboard Positioner CL (from decking) 55.2"
-
Headstock–Tailstock Span 118"
-
Main Axis rotation diameter 95"
-
Secondary Axis Rotation Diameter 43.3"
-
Main Axis Rotation Height 51.2"
-
Robot Height (from floor) 49.7"
-
Light Curtain Opening 159"
-
Robot CL to Positioner Faceplate (single robot cell) 60.4"
- PerformArc PA-360S Welding Cell
- Pansonic HM-350III Dip Pulse Power Supply
- Panasonic TA-1600 Robotic Arm
- Panasonic YA-1NPWW1 Controller
- Panasonic YA-ANBC41 Feeder Control Box
- Light Curtains
Used Panasonic PerformArc 3000. This pre-owned Welding Cell is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Panasonic Welding Cell we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
