Matsuura Cublex-42 PC24 2009

Sold Image

Matsuura Cublex-42 PC24 2009 1

Matsuura Cublex-42 PC24 2009 2

Matsuura Cublex-42 PC24 2009 3

Matsuura Cublex-42 PC24 2009 4

Matsuura Cublex-42 PC24 2009 5

Matsuura Cublex-42 PC24 2009 6

Matsuura Cublex-42 PC24 2009 7

Matsuura Cublex-42 PC24 2009 8

Matsuura Cublex-42 PC24 2009 9

Matsuura Cublex-42 PC24 2009 10

Matsuura Cublex-42 PC24 2009 11

Matsuura Cublex-42 PC24 2009 12

Matsuura Cublex-42 PC24 2009 13

Matsuura Cublex-42 PC24 2009 14

Matsuura Cublex-42 PC24 2009 15

Matsuura Cublex-42 PC24 2009 16

Matsuura Cublex-42 PC24 2009 17

Matsuura Cublex-42 PC24 2009 18

Matsuura Cublex-42 PC24 2009 19

Matsuura Cublex-42 PC24 2009 20

Matsuura Cublex-42 PC24 2009 21

Matsuura Cublex-42 PC24 2009 22

Matsuura Cublex-42 PC24 2009 23

Matsuura Cublex-42 PC24 2009 24

Matsuura Cublex-42 PC24 2009 25

Matsuura Cublex-42 PC24 2009 26

Matsuura Cublex-42 PC24 2009 27

Matsuura Cublex-42 PC24 2009 28

Matsuura Cublex-42 PC24 2009 29

Matsuura Cublex-42 PC24 2009 30

Matsuura Cublex-42 PC24 2009 31

Matsuura Cublex-42 PC24 2009 32

THIS MACHINE HAS SOLD AND IS NO LONGER AVAILABLE. WE MIGHT STILL HAVE A SIMILIAR MODEL OR EXACT MATCH. BROWSE CURRENT INVENTORY OR CONTACT AN AGENT BELOW.

MAKE: Matsuura
MODEL: Cublex-42 PC24
YEAR: 2009
TYPE: 5 Axis Machining Center
CONTROL: Flowmaster 6.7
REF #: 3657787

MACHINE SPECIFICATIONS

Spindle Speed:

12000 rpm
C-Axis Rotation Speed:

1800 rpm
Tool Magazine:

HSK63
X Axis Travel:

20.47"
Y Axis Travel:

28.74"
Z Axis Travel:

20.07"
A - Axis Travel:

-110 ~ + 10 Degrees
C Axis Travel:

360 Degrees
Load Capacity:

440 lbs
Spindle Motor Power:

kW 7.5/11
Magazine Tool Capacity:

320 Tools
Working Surface:

11.81"

MACHINE EQUIPPED WITH

Full 5-Axis w/Turning Option
ChipBlaster JV40 High Pressure Coolant System
LNS Turbo Microfine 2 Chip Conveyor
PC 24 - 24 Tower Pallet Changer
320 Tool ATC
2 - Oil Chillers
Probing
