SNK RB-4M 2015

machine specification

• TABLE SIZE
• 78.7" x 157.5"

• TABLE LOAD CAPACITY
• 30,000lbs

• DISTANCE BETWEEN COLUMNS
• 102.4"

• X-AXIS TRAVEL
• 167.3"

• Y-AXIS TRAVEL
• 114.2"

• Z-AXIS TRAVEL
• 23.6"

• W-AXIS TRAVEL
• 43.3"

• RAPID TRAVERSE (X/Y/Z)
• 787,787,315,197 IPM

• SPINDLE SPEED
• 40-6000 RPM

• SPINDLE TAPER
• 50

• NUMBER OF GEAR RANGES
• 2

• MAIN MOTOR
• 40HP

• AUTOMATIC TOOL CHANGER
• 40ATC

machine equipped with

• FANUC 31IB CNC CONTROL ROUND COLUMN WITH ROUND QUILL 40 POSITION AUTOMATIC TOOL CHANGER 1 POSITION AUTOMATIC ATTACHMENT CHANGER UNIVERSAL ATTACHMENT – 1 DEGREE INDEXING LINEAR SCALE FOR X
• Y
• Z AXIS COOLANT TANK CUTTING AIR BLOW DEVICE CHIP CONVEYOR (2-CONVEYOR TYPE) AUTOMATIC TOOL LENGTH MEASURING FUNCTION BROKEN TOOL DETECTION (TOUCH TYPE) MOVABLE OPERATION PENDANT
