Mazak Integrex 400-IISY 2002

machine specifications

• Z2-Axis Travel:

  43.7"

• Coolant Tank Capacity:

  103.4 gal

• Rapid Feedrate Z:

  1181.1 ipm

• Rapid Feedrate Y:

  590.55 ipm

• Rapid Feedrate X:

  1181.1 ipm

• Milling Spindle Motor:

  20 hp

• Second Spindle Motor:

  30 hp

• Second Spindle Speed:

  3380 rpm

• Main Spindle Motor:

  AC40/30 hp

• Spindle thru hole:

  3.46"

• Max Machining Diameter:

  24"

• Swing over cross slide:

  13.8"

• Main Spindle Chuck:

  15" (Left)

• TOOL CAPACITY:

  40 ATC

• Milling Spindle Maximum Speed:

  10,000 rpm

• Second Spindle Nose:

  A2-8

• Main Spindle Speed:

  2500 rpm

• Main Spindle Nose:

  A2-8

• DISTANCE BETWEEN CENTERS:

  40"

• Max Swing:

  24"

• B-Axis Travel:

  225-Deg

• Z-Axis Travel:

  44.8"

• Y-Axis Travel:

  9.06"

• X-Axis Travel:

  22.83"
