DMG Mori NLX 2500/1250SY 2016

machine specification

• X-AXIS TRAVEL
• 10.2"

• Y-AXIS TRAVEL
• 1.9"

• Z-AXIS TRAVEL
• 53"

• ROTARY TOOL SPINDLE MOTOR
• 10,000 RPM

• CHUCK SIZE 1, 2
• 10" Kitagawa; 6" Kitagawa

• SPINDLE TRAVEL
• 50.5"(B-axis)(2)

• SPINDLE SPEED
• 4000 RPM; 6,000 RPM (1 & 2)

• SPINDLE NOSE
• A2-8; A2-6 (1 & 2)

• SPINDLE MOTOR
• 25 / 20 HP

• RAPID TRAVERSE RATES
• 1181 IPM

• MAX TURNING LENGTH
• 49.4"

• MAX TURNING DIAMETER
• 14"

• MAX SWING OVER BED
• 36.2"

• MAX DIAMETER BAR CAPACITY
• 3.1"

• TURRET POSITIONS
• 12 (All with Live milling)

machine equipped with

• 10" KITAGAWA BB210A821 CHUCK ON MAIN SPINDLE
• 6" KITAGAWA B206A521F CHUCK ON SUB-SPINDLE
• HIGH PRESSURE COOLANT SYSTEM (1000PSI)
• CHIPBLASTER UNIT
• DIRECT SCALE FEEDBACK ON X/Y/Z AXIS
• HYDRAULIC STEADY REST
• CHIP CONVEYOR
