Mori Seiki ZT2500Y 2008

machine specifications

• Bar Capacity:

  3"

• X-Axis Travel (Turret 2):

  7.9"

• Rotary Tool Spindle Speed:

  4,000 RPM

• Spindle bearing inner diameter:

  5.1"

• C-Axis Indexing:

  .001°

• Max Distance Between Centers:

  51.2"

• Max Swing over Cross Slide:

  16.5"

• Max Swing over Bed:

  27.7"

• Max Swing:

  26"

• Max Turning Length:

  13.7"

• Max Turning Diameter:

  15.3"

• Turret Tooling:

  12 Station

• Z-Axis Travel:

  37.8"

• X-Axis Travel:

  11"

• Spindle Motor:

  30 HP

• Spindle Speed:

  4,000 RPM

• Chuck Size:

  10"

• Y-Axis Travel:

  +/- 2.8" (Upper Turret Only)

• Weight:

  31,000 lbs

• Dimensions (approx.):

  18" W x 10'D x 9'H
