Keyence IM-7020 2017

machine specification

• DISPLAY
• 10. 4” LCD monitor (XGA: 1024 × 768)

• IMAGE SENSOR
• 1” 6.6 mega pixel monochrome CMOS

• RECEIVER LENS
• Double Telecentric Lens

• FIELD OF VIEW
• 200 mm × 200 mm 7.87 × 7.87" (4x R50)

• HIGH-PRECISION MEASUREMENT MODE
• 125 × 125 mm 4.92" × 4.92"

• MINIMUM DISPLAY UNIT
• 0.1 µm

• HIGH-PRECISION MEASUREMENT MODE
• ±0.5 µm

• WIDE-FIELD MEASUREMENT MODE
• ±1 µm (W/o stage movement)

• WIDE-FIELD MEASUREMENT MODE
• ±2 µm (With Stage Movement)

• HIGH-PRECISION MEASUREMENT MODE
• ±1.5 µm

• MEASUREMENT ACCURACY (±2?): W/O BINDING
• ±5 µm *1 Wide-field measurement mode)

• W/O BINDING: WIDE-FIELD MEASUREMENT MODE
• ±5 µm *1

• HIGH-PRECISION MEASUREMENT MODE
• ±2 µm*2

• WIDE-FIELD MEASUREMENT MODE WITH BINDING
• ± (7+0.02 L) µm*3

• HIGH-PRECISION MEASUREMENT MODE
• ± (4+0.02L) µm*4

• LIGHT PROBE MEASUREMENT MEASURABLE AREA (XY)
• 90 × 90 mm 3.54 × 3.54"

• MAXIMUM MEASUREMENT DEPTH
• 30 mm 1.18"

• LIGHT PROBE DIAMETER
• ø3 mm ø0.12"

• MEASURING FORCE
• 0.015 N

• REPEATABILITY
• ±2 µm*5

• MEASUREMENT ACCURACY
• ± (8+0.02 L) µm*6

• EXTERNAL OUTPUT OK/NG/FAIL/MEAS
• PhotoMos output

• RATED LOAD
• 24 VDC 0.5 A

• INTERFACE LAN
• RJ-45 (10BASE-T/100BASE-TX/1000BASE-T)

• USB 3.1
• 4 ports (rear: 4)

• USB 2.0 SERIES A
• 2 ports (front: 2)

• HARD DISK DRIVE
• 500GB

• TRANSPARENT
• Telecentric transparent illumination

• RING
• Four division, multi-angle illumination (electric)

• XY STAGE
• 100 × 100 mm 3.94 × 3.94" (electric moving)

• WITHSTAND LOAD
• 5 kg

• Z STAGE MOVING RANGE
• 75 mm 2.95" (electric)

• POWER VOLTAGE
• 100 to 240 VAC 50/60 Hz

• POWER CONSUMPTION
• 430 VA or lower

• POLLUTION DEGREE
• 2

• OVERVOLTAGE CATEGORY
• II

• AMBIENT TEMPERATURE
• +10 to +35 °C 50 to 95 °F

• RELATIVE HUMIDITY
• 20 to 80 % RH (No condensation)

machine equipped with

• KEYENCE INSTANT MEASUREMENT SYSTEM
• IM-7020 IM HEAD UNIT WITH LIGHT PROBE
• IM-7001 IM CONTROLLER UNIT
• IM-M70A IM ACCESSORY SET
• PRINTED MANUAL AND A CD
