Haas DT-1 2011

machine specifications

• X-Axis Travel:

  20"

• Y-Axis Travel:

  16"

• Z-Axis Travel:

  15.5"

• Rapid Rate (X/Y/Z):

  2,400 IPM

• Table Size:

  26" x 15"

• Max Table Load:

  250 LBS

• Spindle Motor:

  15 HP

• Spindle Speed:

  10,000 RPM

• Tool Changer:

  20 ATC

• Max Torque:

  46 ft-lbf

• Max Cutting:

  1200 ipm

• Max Thrust X/Y:

  2550 lbf

• Max Thrust Z:

  4200 lbf

• Max Tool Diameter:

  2"

• Max Tool Length:

  7"

• Chip to chip (avg):

  2.4 s

• Max Tapping Speed:

  5000 rpm

• Coolant Capacity:

  55 gal

• Spindle Taper:

  BT 30
