Mazak Optiplex 3015 Fiber III 2021

machine specification

• NUMBER OF CONTROLLED AXES
• 3

• PROGRAM INPUT SYSTEM
• EIA/ISO

• MINIMUM COMMAND UNIT
• 0.0001 in

• POSITION DETECTION SYSTEM
• Encoder

• MACHINE WEIGHT
• 34,436lbs

• MACHINE UNIT DIMS W X D X H
• 334.21 in x 137.2 in x 79.13 in (Machine Only)

• INSTALLATION DIMS W X D
• 394 in x 240 in (Machine Only)

• ELECTRICAL REQUIREMENTS
• 104KVA

• RAPID TRAVEL SPEED (X, Y)
• 4,724 ipm

• POWER OUTPUT
• 10kw

• MOTION DRIVE SYSTEM
• X, Y Axis/Rack and Pinion Drive Z Axis/Ball Screw Drive

• MATERIAL THICKNESS
• 1.25” (SS & AL), 1.0” (NMS)

• MAX. WORKPIECE WEIGHT
• 4,233 LBS

• Z-AXIS TRAVEL
• 110 mm / 3.94 in

• Y-AXIS TRAVEL
• 1595 mm / 62.8 in

• X-AXIS TRAVEL
• 3110 mm / 122.44 in

• TABLE SIZE
• 5ft x 10ft

machine equipped with

• 10 SHELF FMS TOWER AUTOMATION SYSTEM
• MAZAK MAZATROL PREVIEW G CONTROLLER
• 10KW IPG FIBER LASER OSCILLATOR
• CHILLER
• DUST COLLECTOR

machine description

Used Mazak Optiplex 3015 Fiber III. This pre-owned Fiber Laser Cutting Machine is in great working condition and can be securely delivered to your facility floor. If you have any technical questions about this Mazak Fiber Laser Cutting Machine we can review machine specifications. To request a quote, inquire about rigging and trucking or to schedule an inspection, contact us today.
