machine specification

• X-AXIS TRAVEL
• 174” (Max)

• Y-AXIS TRAVEL
• 86.6” (Max)

• Z-AXIS TRAVEL
• 7.87” (Max)

• RESONATOR
• Fanuc AF-4000iC RF

• POWER OUTPUT
• 4000 Watts

• MAX SHEET SIZE
• 86.6” (Y) x 165.3” (X)

• CUTTING HEIGHT
• HS2010 High Speed Non-Contact

• TYPE
• Flying Optic

• X AXIS DRIVE
• Rack And Pinion

• Y & Z AXIS DRIVE
• High Precision Ball Screw

• MAX. POS. SPEED (X & Y)
• 3,150 IPM

• MAX. POSITIONING SPEED (Z)
• 4,724 IPM

• ACCURACY
• +/-.004”

• PIERCING THIN SHEET
• High Speed

• PIERCING PLATE
• Spatter Free

machine equipped with

• AMNC-F TOUCH SCREEN CNC CONTROL
• FANUC AF-4000IC RF RESONATOR
• HS2010 HIGH SPEED NON-CONTACT CAPACITIVE HEAD
• DUAL HIGH SPEED SHUTTLE TABLES
• AUTOMATIC NOZZLE CHANGER
• AUTOMATIC NOZZLE CLEANER
• AUTOMATIC NOZZLE CALIBRATION PLATE
• WACS FEATURE
• FANUC AC SERVO DRIVE MOTORS
• CUT PROCESS MONITORING
• PRECISE COOLING SOLUTIONS CHILLER
• DONALDSON TORIT TG-4 DUST COLLECTOR
• STEP DOWN TRANSFORMER
