Nisshinbo HTP-1000 1997

machine specifications

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Bar Stock Capacity:

  2.0"

• Table Size - L:

  61"

• Pallet Size (inches):

  25"

• Table Size - W:

  30"

• Resonator ( Type ):

  55

• Wire Traveling Speed:

  22

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Throat Depth:

  9.45"

• Max Material Thickness:

  .250"

• Max Hole Capacity In 14 Gauge:

  3.5"

• Max Hole Capacity In:

  250" 1.125"

• Max Workpiece Size:

  39.375" x 49.6"

• Hits Per Minute On 1":

  Moves 240

• Hits Per Minute (Nibble Mode):

  450

• Punching Force (Hydraulic Servo):

  22 Ton

• Punching Hours:

  7,538

• Power On Hours:

  7,538

• Chuck Size (Inches):

  8"

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm

• Z - Axis Travel (inches):

  14.7" / 375mm

• Max Swing (inches):

  17.32"
