Trumpf Trumatic TC 200 1996

machine specifications

• Wire Traveling Speed:

  22

• Chuck Size (Inches):

  8"

• Z - Axis Travel (inches):

  14.7" / 375mm

• Spindle Taper (CAT/BT):

  HSK-463

• Spindle Speed:

  12,000 RPM

• Max Swing (inches):

  17.32"

• Bar Stock Capacity:

  2.0"

• Pallet Size (inches):

  25"

• Table Size - L:

  61"

• Throat Depth:

  9.45"

• Resonator ( Type ):

  55

• Wire Diameter (inches):

  3333

• Vertical Travel of Ram:

  4444

• V-Axis Travel:

  5555

• Turret Capacity:

  8 Positions

• Tool Changer Type:

  60 ATC

• Table Size - W:

  30"

• Maximum Punching Capacity:

  22 Tons

• Sheet Size Capacity:

  4' x 8'

• Number of Turret Stations:

  18

• Number & Size of Auto Index Stations:

  18 (3")

• Type of Frame Design:

  J-Frame

• Type of Punching Force:

  Hydraulic

• Type of Turret Tooling:

  Trumpf

• Type of CNC Controls:

  Bosch

• X - Axis Travel (inches):

  15.7" / 400mm

• Y - Axis Travel (inches):

  15.7" / 400mm
