You-Ji YV1200ATC+C 2005

MACHINE SPECIFICATIONS

• Vertical travel of cross rail:

  29.5"

• Live Spindle Motor:

  15 HP

• Spindle Drive Motor:

  60 HP

• Spindle Taper:

  BT 50

• AUTOMATIC TOOL CHANGER:

  16 (Pockets)

• Cutting Feedrate:

  .03 - 78.74 IPM

• Rapid traverse of ram (Z-axis):

  393.7 IPM

• Rapid traverse of rail head (X-axis):

  472.44 IPM

• Live Milling:

  2 - 2400 RPM (2 range Spindle speeds)

• Table Speeds (2 Ranges):

  1 - 350 RPM

• Table:

  49.21"

• C-Axis Indexing:

  0.001 Degree

• Z-Axis Travel:

  35.43" (Vertical Travel of Ram)

• X-Axis Travel:

  36.81" (Horizontal Travel of Rail Head)

• Max Table Load:

  11,023 Lbs

• Ram Distance to Table (Max / Min):

  76.6" / 0"

• Max Cutting Height:

  63"

• Max Cutting Diameter:

  53.15"

• Max Swing:

  63"
