This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- 213 Psi Coolant Thru Mill Head
- 5 Axis Simultaneous
- 5 Degree Index Clamp By Courvic Coupling
- Absolute Positioning System
- Rethread
- Thread Point Start Comp
- Visual Tool Id (Prep)
- Additional Memory
- Additional Cutter Comp
- All Available Manuals
- Auto Atlm
- Automatic Tool Eye
- B-Axis .0001 Degree Contouring N/A S/F
- Big Plus Direct Mount
- Chip Conveyor
- Concept Chip Removal System
- Cylindrical & Polar Coordinate
- Eia
- Eia Coordinate Rotation
- Eia/Iso Input 5 Axis Simultaneous
- E-Tower
- Ext-Data I/O
- Flash Tool (Prep)
- G00
- G00 Slope Constant
- G54.1
- Geometric
- High Pressure 213 Psi Coolant Thru The Spindle
- High Speed Hydraulic Pressure Interlock
- Hydraulic Pressure Interlock
- Inch/Metric Conversion
- Lan Port
- Left And Right Spindles .0001 N/C Contouring
- Left And Right Spindles 35 Hp Ac
- Mazatrol Matrix Cnc Conversational Control
- Polar Coordinates Input
- Renishaw Omp 60 Optical Probe W/Inspection
- Software
- Rethread Function
- Rotary Axis Shape Comp
- Rotation
- Scaling / Coordinate System Rotation
- Shape Comp
- Thread
- Inverse Time
- Comparison Stop
- Simultaneous 5 Axis
- Slope Constant/Shape Comp
- Smw Fully Programmable Steady Rest
- Sync. Tap
- Thread Comp
- Tool Radius 5 Axis Simultaneous
- Tool Radius Comp. 5 Axis
- Tool Tip Point Comp. 5 Axis
- Work Measurement System Omp40 Renishaw Probe
- Y-Axis Travel 16.14"
Specifications
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- A – Axis Travel 240 Degrees
- C – Axis Rapids 555 IPM
- C – Axis Travel .0001 Degree
- C – Axis Travel Sub Spindle .0001 Degree
- Spindle Speed 12,000 RPM
- Spindle Bore Main 4.4" Option
- Spindle Nose A2-8
- Max Swing (inches) 17.32"
- Maximum Machining Diameter 24.02"
- Maximum Cutting Length 123.31"
- Tool Changer Type 60 ATC
- Maximum Tool Weight 22 lbs.
- Maximum Tool Length 15.75"
- Maximum Tool Weight 26.5 lbs.
- Rotary Tool Spindle Taper 50 Big Plus
- Rotary Tool Spindle Speeds 12,000 RPM
- Rotary Tool Motor 30 HP
- Max. Tool Dia. / Adjacent Pocket Empty 3.74" / 5.91"
- X, Y, Z – Axis Rapids 1969, 1181, 1969 IPM
- Resonator ( Type ) 55
- Bar Stock Capacity 2.0"
- Chuck Size (Inches) 8"
- Spindle Taper (CAT/BT) HSK-463
- Table Size - L 61"
- Table Size - W 30"
- Throat Depth 9.45"
- Turret Capacity 8 Positions
- V-Axis Travel 5555
- Vertical Travel of Ram 4444
- Wire Diameter (inches) 3333
- Pallet Size (inches) 25"
- Wire Traveling Speed 22
Machine Description
No description available
