This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Activate Search Agent
We'll help you find what you need
Equipped With
- Twin Facing Spindle Design
- Full "C" Axis Spindle Rotation Both Spindles
- Live Milling / Drilling Capability on Both Turrets
- Y Axis on Upper Turret Only
- Collet Chuck - Both Spindles
- 2.5" Bar Capacity Option on Left Spindle
- Chip Conveyor
- Parts Conveyor
- 700 PSI High Pressure Coolant Pump
- Probe
- Glass Scales
- Coolant Tank with Pumps
- RS232 Port Interface
- Boxed Way Design
- All Available Tooling
- All Available Manuals
Specifications
- Bar Capacity 2.55"
- Chuck Type Left / Right Spindle Collet Chuck / Collet Chuck
- Chuck Size 6.5"
- Spindle Motor 20 HP / 15 HP (Both 30 minutes/continuous)
- X-Axis Travel 7"
- Z-Axis Travel 17.71"
- Rapid Rate Z Axis 945 IPM
- Turret Tooling 12 (2) Station
- Rapid Rate X Axis 590 IPM
- Max Turning Diameter 7.87"
- C Axis Spindle Rotation Both: 0.001 Degree
- Max Turning Length 15.75"
- Spindle Nose / Spindle Bore Left / Right A2-6" / 3.15" / 2.56"
- Spindle Speed Left / Right 5,000 RPM / 7,000 RPM
- Max Swing 15.75"
- Y-Axis Travel +/- 3"
- Rotary Tool Speed 6,000 RPM
- Rotary Motor n/a
- Number of Turret Position 12 Station each (Both)
- Rapid Traverse Rates X / Z 590 IPM / 945 IPM
Machine Description
No description available
