This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Activate Search Agent
We'll help you find what you need
Specifications
Equipped With
- Chuck Size 8.3 in
- Full Load Amps (3 Phase) High 20A
- Input AC Voltage (3 Phase) High 440 VAC
- spindle power 20.0 hp
- Spindle Speed 4000 rpm
- Air Required 4 scfm @ 100 psi
- Coolant Capacity 30 gal
- Live-Tooling VDI40
- Live Tool Speed 4000 rpm
- Boring Bar Rear Clearance (from back of turret ) 0.75 in
- Number of Tools 12-Station Hybrid (6 VDI; 6 BOT)
- Quill Travel 3.8 in (Hydraulic)
- Brake Diameter 14.4 in
- Brake Clamp Force 1000 lbf
- Positioning (±) 0.02 °
- Spindle Bore 3.50 in
- Max Speed 60 rpm (Main Spindle C-Axis)
- Max Part Diameter 16.5 in
- Max Cutting Diameter 12.0 in
- Max Cutting Length 16.0 in
- Bar Capacity 2.50 in
- X-Axis Travel 7.9 in
- Y-Axis Travel ± 2.0 in
- Z-Axis Travel 16.0 in
- Rapids on X/Y/Z 472/472/1200 IPM
- Max Thrust X 2400 lbf (Axis Motors)
- Max thrust Y 2300 lbf (Axis Motors)
- Max Thrust Z 3700 lbf (Axis Motors)
- Spindle Nose A2-6
- Max Rating 5.0 hp (Main Spindle C-Axis)
- Max Torque 150.0 ft-lbf @ 500 rpm
- Over Wedge 16.5 in
- Max Rating 20.0 HP
- Max Speed 4000 rpm
- Brake Holding Torque 140 ft-lbf
- Manual Body Positioning 20.0 in
- Max Thrust (Hyd. Quill Only) 1130 lbf
- Min Thrust (Hyd. Quill Only) 140 lbf
Machine Description
No description available
