This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Estimated amount
$1,345.87/month
for over 72 months at 6.75% APR *
Activate Search Agent
We'll help you find what you need
Equipped With
- EIA/ISO Programming
- 213 PSI Flood/Thru Not Simul-Flowable
- 2nd Spindle C-Axis .001 Degree
- Auto Chuck Jaws Open/Close 1st And 2nd Spindle
- Chuck Open/Close Confirmation 1st And 2nd Spindle
- Hydraulic Pressure Interlock
- Milling Spindle Synchronous Tapping
- 6" Chuck Bb-06 For Diameter 2" Bar Capacity 1st Spindle
- 6" Chuck Non Thru Hole On Sub
- Automatic Parts Catcher
- Turret Airblast
- Chip Conveyor - Rear Exit
- Prep For Multi And Flash System
- ATS A-5 3j Collet Main Spindle
- Parts Ejector For 2nd Spindle Collet Nose
- 30+ KM63 tool holders
Specifications
- Wire Traveling Speed 22
- Resonator ( Type ) 55
- Spindle Taper (CAT/BT) HSK-463
- Chuck Size (Inches) 8"
- Pallet Size (inches) 25"
- Table Size - L 61"
- Table Size - W 30"
- Throat Depth 9.45"
- Turret Capacity 8 Positions
- V-Axis Travel 5555
- Vertical Travel of Ram 4444
- Wire Diameter (inches) 3333
- Max Swing (inches) 17.32"
- Max Swing Over Carriage 11.42"
- Maximum Cutting Diameter 18.5"
- Maximum Cutting Length 29.72"
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Travel B Axis 225 Deg/.001 Deg
- Spindle Nose A2-5
- Spindle Bore 2.4"
- Bar Stock Capacity 2.0"
- Spindle Speed 12,000 RPM
- Spindle Motor (HP) 10 HP
- Main & Subspindle Indexing .001 Degree
- Rotary Tool Motor 7.5 HP
- Rotary Tool Speed 10,000 RPM
- Tool Changer Type 60 ATC
- Rapid Traverse Rate X 1181 IPM
- Rapid Traverse Rate Y 1024 IPM
- Rapid Traverse Rate Z 1299 Ipm
Machine Description
No description available
