This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Estimated amount
$3,809.07/month
for over 72 months at 6.75% APR *
Activate Search Agent
We'll help you find what you need
Equipped With
- Fanuc 31i-A5 2path CNC Control
- AICCII / Jerk Control
- NT Nurse Ii System
- Nt Navigator
- OMP 60m/Lp2 Tool Setter
- LPE2 100mm Extension
- Tool Setting Styli / Tool Setting Software Fanuc
- Nc4 Laser Probe Tool Set On B-Axis
- In-Process Measurement
- Tool Center Point Control
- Tilted Work Plane
- Capto C4 Shank
- Parts Catcher A -9 Controlled Axes
- Chamfering And Corner Rounding
- Arc Radius R Programming
- Multiple Repetitive Cycles
- Polar Coordinate Interpolation
- Cylindrical Interpolation
- Balance Cut
- Thread Cutting
- Abnormal Load Detection -N-T Nurse Tool Monitoring Function
- Excessive Load Detection
- Navigator Function For Part And Datum Point Recognition
- Fixed Air Blow Off Both Systems
- (2) 6.5" 3 Jaw Hydraulic Chucks L/R
- Y- Axis Upper Turret
- Milling Both Turrets
- Synchronized Z Axes
- Hydraulic Pressure Interlock
- Milling Spindle Sync. Tap
- Chip Conveyor
- All Available Standard Turning Tool Holders
- All Available Manuals
- 1 - Tool Box
- 1 - Electrical Parts
- 1 - Chuck Parts (chuck wrench
- bracket
- allen wrenches)
- 1 - Shipping Brackets
- 1 - Tool Holder RH (C21441)
- 1 - Cut Off Holder LH (C21431)
- 1 - Double Boring Holder (C22413)
- 2 - Double Turning Holder (C21417)
- 4 - Tool Holder A (C21411)
- 2 - 3/8 Bushing (M2120)
- 2 - 1/2 Bushing (M2121)
- 2 - 5/8 Bushing (M2122)
- 2 - 3/4 Bushing (M2123)
Specifications
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- B Axis Speed / HP 12,000 RPM / 10 HP
- B-Axis Travel - Pendulum Head 190 Deg. (+/- 95 Deg.)
- Resonator ( Type ) 55
- C Axis Movement - Both Spindles .001 Degree
- W Axis Travel 30.3" (Sub spindle)
- Spindle Speed 12,000 RPM
- Spindle Motor (HP) 15 HP (Both)
- Spindle Nose A2-5
- Thru Spindle Hole Diameter 2.48"
- Chuck Size (Inches) 8"
- Rapid Feed X1/X2 1182/630 IPM
- Rapid Feed Z1/Z2 1576/1576 IPM
- Rapid Feed B2 1576 IPM
- Rapid Feed Y 630 IPM
- Tool Changer Positions 2 x 24 ATC Pos (48 Total)
- Max Swing over Cross Slide 8.07"
- Max Turning Diameter 7.87"
- Standard Turning Diameter 6.69"
- Main Max Bar Capacity 2.04" (Both Sides)
- Lower Turret Positions 24 Dodecagonal Drum Turret
- Tool Shank Capto C4
- Power On Hours 9,073
- Spindle Taper (CAT/BT) HSK-463
- Bar Stock Capacity 2.0"
- Wire Diameter (inches) 3333
- Wire Traveling Speed 22
- Pallet Size (inches) 25"
- Max Swing (inches) 17.32"
- Vertical Travel of Ram 4444
- V-Axis Travel 5555
- Table Size - L 61"
- Table Size - W 30"
- Throat Depth 9.45"
- Tool Changer Type 60 ATC
- Turret Capacity 8 Positions
Machine Description
No description available
