TT24
2013
Milltronics
#3702269

Specifications

Equipped With

  • X Axis Travel 23″ (585 mm)
  • Y Axis Travel 25″ (635 mm)
  • Z Axis Travel 20″ (510 mm)
  • Table Size 22″ x 26″ (560 mm x 660 mm) (2)
  • Allowable Table Load 2000 lbs. (900 kg)
  • T-Slot Size .63″ (16 mm)
  • Spindle Gage Line to Table 4″-24″(100-610 mm)
  • Spindle Taper ISO No. 40 Big Plus®
  • Spindle speed (Std) 10,000 RPM
  • Spindle speed (Opt) 15,000 RPM
  • AC spindle motor (Std) 24/15 HP (18/11 kW) Inline Delta/WYE
  • AC spindle motor (Opt) 35/25 HP (26/18 kW) Inline Delta/WYE
  • Spindle torque (Std) 85 ft-lbs(115 N.m)
  • Spindle torque (Opt) 122 ft-lbs(165 N.m)
  • Axis thrust force X/Y,Z 1000/2000 lbs (450/900 kg)
  • Spindle Speed 10,000 RPM
  • ATC Type Double Arm
  • Number of Tools 24
  • Tool Shank CT40
  • Max. Tool Diameter 4″
  • Max. Tool Length 11″ (280 mm)
  • Max. tool weight 15 lbs. (7 kg)
  • Max. Cutting Feedrate 500 IPM (12.7 m/min)
  • LEAST COMMAND INCREMENT 0.0001″ (0.001 mm)
  • Positioning Accuracy +/- 0.0002″ (+/- 0.005 mm)
  • Repeatability 0.00015″ (0.0038 mm)
