This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Activate Search Agent
We'll help you find what you need
Specifications
Equipped With
- Max Turning Diameter 10.6 (270) in (mm)
- DRIVEN TOOL SPINDLE 7.5 HP
- Main Spindle 25 HP
- Number of Tool Stations 24
- Least input increment 1E-3 degree
- Right Spindle Nose A2-6
- Right Spindle Speed 4500 rpm
- RIGHT SPINDLE 4500 rpm
- Left Spindle Nose A2-8
- Left Spindle Speed 3500 / 2500 rpm
- Rapid Feed Z1/Z2 1063 (27) / 1063 (27) in/min (m/min)
- SLIDE TRAVEL B 33.5 (850) in (mm)
- Capacity ø3.2 in ( 80) / ø4 (102) (op.) in (mm)
- Distance Between Spindles 43.3 (1100) / min 9.8 (250) in (mm)
- Max Turning Length 30.7 (780) in (mm)
- Bar Capacity 4 (102) (op.) in (mm)
- Chuck Size 8"
- SLIDE TRAVEL X1/X2 7.4 (188) / 7.7 (195) in (mm)
- Slide Travel Z1/Z2 30.7 (780) / 30.7 (780) in (mm)
- Slide Travel Y ±2.4 (60) in (mm)
- Rapid Feed X1/X2 630 (16) / 630 (16) in/min (m/min)
- BAR CAPACITY L-SPINDLE 3.2 in (80 ) in (mm)
- BAR CAPACITY R-SPINDLE 2.6 (65) in (mm)
- LEFT HOLE THROUGH DRAW TUBE 3.2 (81) / 4 (103) in (mm)
- RIGHT HOLE THROUGH DRAW TUBE 2.5 (66) in (mm)
- ROTARY SYSTEM/NUMBER OF DRIVEN-TOOL STATIONS 24
- RIGHT SPINDLE SPEED RANGE Stepless
- NUMBER OF ROTATION TOOL STATION 12×2
- SUB SPINDLE (OP.) 25
Machine Description
No description available
