This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Activate Search Agent
We'll help you find what you need
Specifications
Equipped With
- Max Machining Length 39.8"
- Tool Changer Type 60 ATC
- Chuck Size (Inches) 8"
- Spindle Taper (CAT/BT) HSK-463
- Pallet Size (inches) 25"
- Table Size - L 61"
- Table Size - W 30"
- Throat Depth 9.45"
- Turret Capacity 8 Positions
- V-Axis Travel 5555
- Vertical Travel of Ram 4444
- Wire Traveling Speed 22
- Resonator ( Type ) 55
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Bar Stock Capacity 2.0"
- Spindle Speed 12,000 RPM
- Max Swing (inches) 17.32"
- Wire Diameter (inches) 3333
- B - Axis Travel 240 Degrees (-30, +210)
- C - Axis Travel Main Spindle .0001 Degree
- W - Axis Tailstock Travel 41.97"
- Milling Speed 12,000 RPM
- Spindle Speed (Sub) 5,000 RPM
- Spindle Nose A2-6
- Main Spindle Bore 2.99"
- Main Spindle Output 30 HP
- Full 5 Axis Simultaneous Milling
- Maximum Swing over Bed 25.9''
- Maximum Machining Diameter 25.9"
- Maximum Cutting Length 39.8"
- Second Spindle Nose A2-6
- Second Spindle Speed 5000 RPM
- Second Spindle Indexing .001 Degree Programmable
- Second Spindle Output 25 HP
- Rapid Traverse Rates X, Z, W, Y 1969, 1969, 1181, 1575 IPM
- Rapid Traverse Rate B, C 40, 555 RPM
- Rotary Tools Spindle Nose CAPTO
- Tool Magazine Capacity 36 ATC
- Rotary Tool Spindle Speeds 12,000 RPM
- Rotary Tool Motor 30 HP
- Max Tool Length 15.75''
- Max Tool Dia. / Adjacent 3.54''/4.92''
Machine Description
No description available
