This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Equipped With
- 2 x Kitagawa N-8 (8") Hydraulic chuck w/ closed center
- Highly Rigid Box Guide Ways XL/ XR/ ZL/ and ZR axes
- Type C Gantry Loader System
- 2 x Work Feeder (16 Pallets w/ 3 Poles of Guide Bar)
- Raku-Raku Loader Software (Takisawa Loader Programming Software)
- Raku-Raku Monitor Software (Takisawa Tool Counter/ Tool Life Management)
- Gantry Loader Interface and Pendant Control
- Chip Conveyor (Rear Discharge Type)
- Loaded Air Blow
- 2 x Programmable Air Blow for Chuck by M-Function
- 2 x 10 Station Tool Tool Turret
- Two (2) Spindle Speed Upgrade to 4500 rpm
- Two (2) Coolant Pump Upgrade to 520W Grundfos Pump
- Two (2) Microcentric CB80-NX/140 Collet Chuck Dead Length
- Two (2) Adaptor Plate
- Five (5) Quick Change Collet
- One (1) 3.5" Special Quick Change Collet
- One (1) CM-80 Quick Grip Collet Manual Installation Tool
- Four (4) O.D. Tool Holder Included
- Six (6) Round Tool Holder
Specifications
- Number of Spindles 2
- Spindle Horsepower 14.7 / 10
- Number of Tools 10+10
- Turret Capacity 10+10
- Spindle Motor (HP) 14.7 / 10
- Spindle Speed 4500 RPM
- Chuck Size (Inches) (2) 8"
- X - Axis Travel (inches) 5.59"
- Z - Axis Travel (inches) 6.5"
- Number of Turrets 2
- Max Turning Diameter 9.45"
- Max Turning Length 3.70"
- Distance Between Spindles 13.38"
- Through Hole 2.09" Diameter
Machine Description
No description available
