This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Estimated amount
$2,023.04/month
for over 72 months at 6.75% APR *
Equipped With
Specifications
- Max Swing (inches) 17.32"
- Resonator ( Type ) 55
- Chuck Size (Inches) 8"
- Bar Stock Capacity 2.0"
- Pallet Size (inches) 25"
- Table Size - L 61"
- Table Size - W 30"
- Tool Changer Type 60 ATC
- Wire Traveling Speed 22
- Wire Diameter (inches) 3333
- Vertical Travel of Ram 4444
- V-Axis Travel 5555
- Turret Capacity 8 Positions
- Throat Depth 9.45"
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Pallet Working Surface (2) 500mm x 500mm
- Maximum Table Load 1,100 lbs per pallet
- Spindle Speed 12,000 RPM
- Spindle Motor (HP) 24 HP
- Spindle Taper (CAT/BT) HSK-463
- Spindle Nose to Table 6.1” to 30.12”
- B Axis Motion 360 Degrees
- Coolant Capacity 153 Gallons
- B Axis Feedrate 33.3 RPM
- B Axis Clamping Force (4 cone clamp system) 10,000 lbs
- B Axis Clamping Force ( Rotational ) 1,100 lbs
- Pallet Top (24) - M16 Hole Matrix on 3.94” Centers
- Spindle Motor Torque (1 min.) 175 Ft. lbs @ 720 RPM
- Rapid Traverse Rate X,Y and Z 1,260 ipm
- Cutting Feed Rate 600 ipm
- LEAST COMMAND INCREMENT 0.0001”
- Positioning Accuracy X,Y/ Z -/+ 0.0002”
- Repeatability X,Y/Z -/+ 0.0001”
- Pallet Exchange Time 8 Seconds
- Positioning Accuracy B Axis 8 Arc-seconds
- Repeatability Accuracy B Axis +/- 2 Arc-seconds
- Number of Stations 60 / CAT 40
- Tool To Tool ATC Time 2.5 Seconds
- Tool Changer Type Electronic
- Maximum Tool Diameter 3.2”
- Maximum Tool Length 13.8”
- Voltage Required 208-240 VAC / 60Hz
- Power Rating 60 KVA
- Air Requirements 5 CFM @ 80-100 psi
Machine Description
No description available
