This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Estimated amount
$5,485.07/month
for over 72 months at 6.75% APR *
Equipped With
Specifications
- X - Axis Travel (inches) 15.7" / 400mm
- Y - Axis Travel (inches) 15.7" / 400mm
- Z - Axis Travel (inches) 14.7" / 375mm
- Spindle Speed 12,000 RPM
- Spindle Taper Hole 7/2 No. 40 Taper (*HSK-A63)
- Pallet Size (inches) 25"
- Maximum Pallet Load 882 lbs.
- Distance from Pallet Surface to Spindle Center 3" - 28"
- Distance From Pallet Center to Spindle Gauge Line PLane 4" - 29"
- Tool Changer Type 60 ATC
- Tool Changer Positions 60
- Type of retention knob JIS B6339 40P
- Maximum Tool Weight 26 lbs
- Type of Tool Shank JIS B6339 40T
- Maximum Tool Diameter 70/7"
- Maximum Workpiece Size 25" x 35"
- Rapid Traverse 2,3362" / min
- Cutting Feed 1 - 1,969" / min.
- Electrical power supply AC200 V±10%50 / 60 Hz ±2% 50 kVA
- Compressed air supply 0.5 – 0.8 Mpa, 410L/ min
- Resonator ( Type ) 55
- Spindle Taper (CAT/BT) HSK-463
- Bar Stock Capacity 2.0"
- Turret Capacity 8 Positions
- V-Axis Travel 5555
- Vertical Travel of Ram 4444
- Wire Diameter (inches) 3333
- Wire Traveling Speed 22
- Max Swing (inches) 17.32"
- Throat Depth 9.45"
- Table Size - L 61"
- Table Size - W 30"
- Chuck Size (Inches) 8"
Machine Description
Pallet: 15.7" x 15.7" / 400 x 400 mm
X: 22.0" / 560 mm
Y: 25.2" / 640 mm
Z: 25.2" / 640 mm
Spindle RPM:14,000 rpm (14K High Torque, 20K)
Rapid Traverse: 2,362 ipm 60,000 mm/min
Cutting Feedrate: 1,968 ipm 50,000 mm/min
Maximum Workpiece: ø24.8" x 35.4" / ø630 x 900mm
Maximum Payload: 880 lbs / 400 kg
ATC Capacity: 60 tools
Tool to Tool: 0.9 secs
Chip to Chip: 2.2 secs
Maximum Tool Length: (Cat)16.9" / 430 mm
Maximum Tool Length: (HSK)16.5" / 420 mm
Maximum Tool Diameter: 6.7" / 170 mm
Maximum Tool Weight: 26.4 lbs
