This Machine has been sold and is No longer Available... Find similar machines below
SOLD
Activate Search Agent
We'll help you find what you need
Equipped With
- Fanuc 31i Control
- NC 4th Axis 360000 Position Rotary Indexing Table
- 6000 RPM Super-Duty Geared Head Spindle
- High Pressure Coolant Thru Spindle (up to 1000 PSI)
- Renishaw OMP60 Optical Probing System with SMT Inspection Software
- Helical Interpolation
- Tool Offset Memory "C" (Geometry and Wear)
- AI Precision Control II (reduces block processing time to 2 ms increases buffer to 200 blocks)
- High Speed Processor (reduces block processing time to .0 ms increases buffer to 600 blocks)
- Workpiece Coordinate System - 48 Sets
- Extended CNC Program Memory
- Custom Macro w/Additional Common Variables
- Integrated Ethernet and Memory Card Input/ Output
- 225 Gallon Coolant Resevoir with (2) pumps for Flood Coolant and Chip Wash
- Direct Tapping
- Isolated Re-Circulating Supply Unit
- Overhead Coolant Shower
- Integrated MistBuster 2000 Mist and Smoke Collector
Specifications
- Pallet Dimension 800 x 800 mm / 31.5" x 31.5"
- Pallet index time 0–90° 5.0 s
- Pallet Height from Floor 1,300 mm / 51.18"
- Pallet Change Time 40.0 s
- Max Load on Pallet 2.500 kg / 5,511 lbs
- X-Axis Stroke 53.14" (Table)
- Y-Axis Stroke 55.11" ( Spindle Head)
- Z-Axis Stroke 45.27" (Column)
- Spindle Nose to Table Center 200-1,350 mm /7.8" - 53.1"
- Spindle Nose to Pallet Top 50 -1,200 mm / 1.9" - 47.24"
- Workpiece (Swing Dia x Height) 1600 mm x 1300 mm / 62.9" x 51.18"
- Max Spindle Speed 6,000 min-1
- Spindle Taper (Big Plus) 50
- Front bearing Ø (mm) Ø 110 mm
- X/Y/Z Ballscrew Diameter 63/50/63 (Ø/mm)
- Cutting Feedrate 1- 24,000 mm/min / 1- 944"
- Rapid Traverse Rate 24 m/min
- Positioning Accuracy ±0.003 mm
- Repeatability ±0.0015 mm
- Table Positioning Accuracy ±2 WS
- Tool holding capacity Chain 60
- Max. tool dimensions 120 x 800 (Ø x length) mm
- Max. tool weight 35 kg
Machine Description
This large used horizontal mill has a full fourth axis, a 800mm x 800mm pallet size, a 60 ATC, 53.1"X x 45.2"Y x 45.2"Z travels, a 6K rpm Spindle Speed with 60HP, a 1000 psi thru spindle coolant, a CAT 50 Spindle Taper, and a 360 degree B axis travel. This HMC is equipped with a Renishaw OMP60 Optical Probing system with SMT inspection software, Ai precision control II, a high-speed processor, and direct tapping capabilities. This mill was built in 2009 and installed new in 2011, was kept in a very clean shop, and has been enrolled in a maintenance program since installation. For more information, please call 312.266.4160.
